The all-rounder at it's best

The brilliant and versatile Sparx 18, with 37x 40W LED power, enables impressive washlight applications in completely innovative dimensions thanks to the innovative TwinZoom. The basic color temperature of the Sparx 18 is freely selectable and it runs extremely quietly thanks to special heatpipe cooling.

The optical system guarantees perfectly homogeneous illumination and enables fascinating color gradients with uniquely diverse beam effects and shapes from Soft Edge to Hard Edge for lighting design at its absolute best.

Technical data

  • 37 RGBW high-performance LEDs of 40 W each
    23,000 lm; CRI > 85
  • > 20,000 h LED life time
  • Flicker-free operation, camera mode: 100, 120 and 600 Hz
  • TwinZoom zoom range: 3° to 70° (1:23)
  • Highly efficient optics for perfect color mixing
  • Individual LED control - Single pixel control
  • Sparkle channel for dynamic effects
  • Multiple layers with independent patterns can be stacked on top of each other
  • Countless color and pattern combinations
  • Glow channel and color spread channel as additional color effects
  • Separate CTC channel
  • Optimised color mixing behaviour
  • High-resolution, steplessly variable dimmer 0–100%
  • Color-accurate dimming
  • Electronic strobe with pulse and random effects
  • TwinZoom effects: Multicolor beams and innovative beam shapes
  • Basic color temperature can be selected: 2700 K, 3200 K, 4200 K, 5600 K, 6000 K, 6500 K, 7000 K oder 8000 K
  • High-resolution 3 phase stepping motors
  • Precise, extreme fast and silent movement
  • 540° Pan / 330° Tilt
  • Protocol: USITT DMX-512, RDM
  • Ethernet / Artnet - sACN - Kling-Net
  • Wireless DMX / RDM / CRMX TiMo - Lumen Radio
  • Bluetooth, WLAN
  • Color touch display with function keys and battery backup
  • Mini USB for software update
  • Stand-alone mode
  • Master/slave function, Built-in DMX analyser
  • Robust, roadworthy design
  • Individually changeable LEDs
  • Patented cooling system - super silent
  • Fan control for virtually noiseless operation
  • Graphical display, electronically rotatable
  • Neutrik 5pin XLR IN / OUT
  • Neutrik etherCON RJ45 IN/OUT
  • Neutrik PowerCON TRUE1 IN / OUT
  • 2 omega brackets with original Camloc connectors for quick and comfortable mounting in any direction with four different mounting possibilities
  • Max. power consumption approx. 1300 VA
  • Input voltage range 100 – 240 V, 50/60 HZ
  • Dimensions: W 481 x H 580 x D 308 mm
  • Weight: 22 kg
  • Schuko on powerCON TRUE1,
    flexible rubber cable (2 m long, 3 x 1.5 mm²)
  • 2 Omega brackets

TWINZOOM-EFFECT

Exclusively from JB-Lighting - the patented TwinZoom. With the TwinZoom, the outer LED ring and the inner area can be zoomed separately from each other - completely infinitely variable from 3°–70° (1:23). Together with the LED single pixel control, absolutely innovative, aesthetically pleasing and effective light scenes can be created, of which one did not dare to dream.

BASIC COLOR TEMPERATURE CAN BE SELECTED


The basic color temperature, from which all colors are automatically mixed, is freely selectable on the Sparx 18, making it an excellent addition to any lighting ensemble.
2700 K
3200 K
4200 K
5600 K
6000 K
6500 K
7000 K
8000 K

STEPLESS ZOOM: 3° – 70° (1:23)


The luminosity and zoom range of 3°–70° of the Sparx 18 are impressive. Virtually noiseless, absolutely precise and fast, the Sparx 18 changes from extremely narrow to wide beam distribution. When TwinZoom is used, you can be sure of its wow factor.
Narrow beam (min. 3°)
Wide distribution (max. 70°)

HARD EDGE & SOFT EDGE


Precise and extremely homogeneous light projections can be created thanks to the diffused light-optimised beams of the Sparx 18 – based on the large and completely borderless transparent lenses, which are lined up almost seamlessly with one another, and with the help of the TwinZoom.
Hard Edge
Soft Edge

MULTICOLOR BEAMS & BEAM SHAPES


The Sparx 18 makes it possible to produce the highest quality multicolor beams and color gradients. Impressive beam shapes can also be achieved which are unique in this form.

OPTIONAL: BEAMSHAPE MODULE


The continuously rotatable and positionable beam shape creates asymmetrical, oval beams. This beam form is suitable e.g. in the theatre excellent as an aisle light or at trade fairs for the illumination of rectangular objects. Of course, the TwinZoom can also be used in this case to individually adjust the beam width and characteristics. In combination with the endless rotation of the Beamshape module, extremely dynamic, circular animation effects can also be achieved.

References

Theater Basel
Festspielhaus Baden-Baden
Stadthalle Biberach
VCC Vogel Convention Center
Landestheater Detmold
Atlantis Audio
Theater Basel
Festspielhaus Baden-Baden
Stadthalle Biberach
VCC Vogel Convention Center
Landestheater Detmold
Atlantis Audio
Theater Lüneburg
CGS Licht und Tontechnik
Komödie am Kurfürstendamm Schiller Theater
Theater Freiburg
Die Theater Chemnitz
Guest Reservations Berlin
Theater Lüneburg
CGS Licht und Tontechnik
Komödie am Kurfürstendamm Schiller Theater
Theater Freiburg
Die Theater Chemnitz
Guest Reservations Berlin
Our Sparx 18 is already providing one highlight after another here.

Testimonials

The high quality, ease of servicing and direct exchange of knowledge with the manufacturer were crucial for us when buying JB devices.

Peter Kanneberger
Peter Kanneberger
Cassiopeia Veranstaltungstechnik GmbH

The JB Sparx 18 are ideally suited to our very wide (18 m) T.3 stage, as these moving light spotlights cover a zoom range of 3-70 degrees. Another advantage is that these spotlights fulfil two functions within one device for us: it is possible to selectively illuminate a performer and to make the area around them a different colour, and all this can be done with one spotlight. Furthermore, the Sparx 18 are hung at around 6 m in the auditorium. No fan noise can be heard by the audience, and this had long been a major problem before. Finally, we are also able to deploy moving lights in the performance, as the movements and functions are quiet and unobtrusive.

Richard Busse
Event technician for Junge Bühne T.3

The JB Sparx 18 are ideally suited to our very wide (18 m) T.3 stage, as these moving light spotlights cover a zoom range of 3-70 degrees. ...

Richard Busse
Richard Busse
Event technician for Junge Bühne T.3

That works!

Real bespoke work – the perfect accessory for the Washbeam Sparx 18
„Made in Germany“

SINGLE FLIGHT CASE

AMPTOWN
  • Pro case made from 10 mm birch plywood with SiP insert, stacking troughs and a scan window
  • Original amptown cases Blue Wheels
  • Dimensions: L 60 x W 60 x H 80 cm
  • Weight (incl. devices): ca. 42 (64) kg

DOUBLE FLIGHT CASE

AMPTOWN
  • Pro case made from 10 mm birch plywood with SiP insert, stacking troughs and a scan window
  • Original amptown cases Blue Wheels
  • Dimensions: L 100 x W 60 x H 80 cm
  • Weight (incl. devices): ca. 60 (104) kg
